• CE Approved and NFPA -72 Standard.
  • 20 x 4 dot matrix LCD display.
  • Operates on 120 - 220VAC 60 /50 Hz, AC mains power supply.
  • Standby (battery) backup 24 VDC power supply with built in charger.
  • Wide range of operating voltage.
  • Touch keypad for user friendly operation.
  • Epoxy powder coated finish.
  • Class- B, Style B / C Initiating Device Circuit (IDC).
  • All zones accept smoke detectors and normal open contact devices.
  • Class B Notification Appliance Circuits (NAC).
  • NAC shall be programmed as AUTO SILENCE / Silence Inhibit.
  • Error free Fire / Fault status in unambiguous colored LED indication.
  • 1000 Event storage with RTC.
  • Main, Standby status with audible and visual indication.
  • IDC labelling facility in display.
  • Each IDC have dedicated LED for Fire, Fault, Isolate and walk test
  • Potential free contact for fire and fault.
  • Resettable / Steady 24VDC. Output.
  • RS 485 Communication facility.
  • TCP/IP facility (Optional).
  • MODBUS for Building Management System integration (Optional).
  • PC software (optional).
  • External zone wise sounder/contact via RS 485 (Optional).
  • All field wiring circuits are supervised.
  • Zone Isolation facility with loop voltage cut off.
  • Zones available : 12, 16, 20, 24, 32, 48, 64,96 and 128.
  • Facility to connect Public Address System (PA) through RS-485 Communication.
  • Peer to Peer network facility.
  • Maximum 16 panels can be connected to a single network.
