Addressable Multi Sensor Detector
RE – 317 D SHL
Overview
Addressable multi sensor detector(s) are designed to work with Addressable panel. These detectors are low profile, polarity free and have dual LED’s for 360° visual indication. The LED’s are blinking in normal operating condition whereas the LED’s in steady state indicate fire status. The fixed cum rate of rise heat detector works using a thermistor. These detectors will raise an alarm when the detector reaches 59°C (Fixed) or when the change in temperature exceeds the rate of rise @ 11°C / min. It has an unique chamber designed to sense smoke produced by wide range of sources of combustion with insect free. The detectors sensitivity can be programmed via FACP. It has a unique drift compensation feature wherein the detector adjusts its normal reference based on environment conditions.
Share This :
- UL listed and NFPA standard.
- Polarity free, Dual LED’s for 360° visibility.
- Insect Filter.
- Fixed temperature and rate of rise detection.
- Advanced detection and communication protocol.
- Easy to install.
- Sleek low‐profile housing design.
- Regular 100 mm base.
- Address set by 8 digit DIP switch.
